Michael Riedel單相變壓器RSTS 25000
| 吳亞男 QQ：2853369884 手機：17718583804 電話：010-64714988-212 傳真：010-64714988-668 郵件：tk2@handelsen.cn |
 |
Michael Riedel 單相變壓器RSTS 25000
RSTS 500 - 25000 UL-CSA
RSTS UL-CSA（-A）系列的特殊優勢：
客戶
Pri的可變電壓選擇選項。額定電壓范圍110V ... 600V含任何數量的抽頭可能的（最大660V）
秒。10V 600V ...（500到3000VA），19V 600V ...（4200-6300VA），40V 600V ...（8000到13000VA），80V ... 600V（16000到25000VA），包括任意數量的水龍頭（最大660V）
最多4個獨立繞組，其總和在電壓范圍窗口內
可靠性高，壽命長
整體損失低，效率高
高電壓穩定性（空載運行和負載運行之間的低壓降）
根據客戶要求，二次電壓可達AC 50V（開路電壓），不可選擇絕緣電纜連接
可選：PE連接螺釘端子，PE屏，熱敏開關
自耦變壓器* 1適應建筑工程
執行：
開放式設計，固定式，用于設備安裝和干燥房間的安裝。通過螺釘連接連接防蠕變變壓器端子。根據UVV（BGV A3），變壓器端子是手背和手指防觸摸。從50A開始，帶有接線端子。
IP00，適用于安裝防護等級IP23，自然空氣自冷，絕緣等級B，最大 環境溫度40°C
單相變壓器25KVA，直立版本，UL / CSA認證
輸入110V 600V ......任何可能的抽頭數（最大660V）含
輸出10V ... 600V（500-3000VA）19V，600V ...（ 4200-6300VA），40V ... 600V（8000-13000VA），80V ... 600V（16000-25000VA）含任何數量的抽頭。（最大660V）
的RSTS UL-CSA系列變壓器是專為北美市場獲得批準并符合國際全球法規。
UL-文件編號：E164203 /分類：XPTQ2 / 8
（而不是“僅金相結構”或“絕緣系統”）
* 1 Suffi X -A（RSTS UL-CSA-A）=自耦變壓器
Michael Riedel RSTN 50
Michael Riedel RSTN 75
Michael Riedel RSTN 100
Michael Riedel RSTN 130
Michael Riedel RSTN 200
Michael Riedel RSTN 250
Michael Riedel RSTN 320
Michael Riedel RSTN 400
Michael Riedel RSTN 500
Michael Riedel RSTN 630
Michael Riedel RSTN 800
Michael Riedel RSTN 1000
Michael Riedel RSTN 1100
Michael Riedel RSTN 1300
Michael Riedel RSTN 1600
Michael Riedel RSTN 2000
Michael Riedel RSTN 2500
Michael Riedel RSTN 3000
通用控制變壓器系列URST具有多個主要分接頭和2至6個分接頭。 它們的使用建議在狹窄的存儲空間和高品種的需求的情況下，使得許多不同的單相控制變壓器的使用不敏感。
Michael Riedel RSSTN 400
Michael Riedel RSSTN 500
Michael Riedel RSSTN 630
Michael Riedel RSSTN 800
Michael Riedel RSSTN 1000
Michael Riedel RSSTN 1100
循環電流測量變壓器
ASK 130.3型
傳動比（300-1600）A /（5,1）A
功率2.5、5、10、15、30VA精度
等級1,0.5、0.2s
初級導體130 x 25mm 環形導體
Ø25mm
變壓器長度50mm變壓器
寬度180mm
變壓器高度100mm
MBS型號示例：
MBS ASR 14.3
MBS ASR 20.3
MBS ASR 21.3
MBS ASR 21.5
MBS ASR 22.3
MBS ASR 22.3 2U
MBS ASR 201.3
MBS ASR 42.45
MBS AS 176.3
MBS ASK 176.3
MBS ASK 205.3
MBS ASK 21.3
MBS ASK 31.3
MBS ASK 31.3 2u
MBS ASK 31.5
MBS ASK 31.5 2u
MBS ASK 31.6
MBS ASK 318.3
MBS ASK 31.4
MBS ASK 31.4 2u
MBS ASK 31.4 3u
MBS ASK 41.3
MBS ASK 421.4
MBS ASK 41.4
MBS ASK 41.4 2u
MBS ASK 41.4 3u
MBS ASK 41.5
MBS ASK 41.6
MBS ASK 412.4
MBS ASK 412.4 2u
MBS ASK 412.4 3u
MBS ASK 541.4
MBS ASK 51.4
MBS ASK 51.4 2u
MBS ASK 51.4 3u
MBS ASK 561.4
MBS ASK 51.6
MBS ASK 61.4
MBS ASK 61.4 2u
MBS ASK 61.4 3u
MBS ASK 61.6
MBS ASK 63.6
MBS ASK 81.4
MBS ASK 81.4 2u
MBS ASK 81.4 3u
MBS ASK 63.4
MBS ASK 83.4
MBS ASK 101.4
MBS ASK 101.4 2u
MBS ASK 103.3
MBS ASK 105.6
MBS ASK 105.6 N
MBS ASK 123.3
MBS ASK 103.41
MBS ASK 127.4
MBS ASK 127.6
MBS ASK 128.4
MBS ASK 129.10
MBS ASK 130.5
MBS ASK 130.3
MBS ASK 31.6
MBS ASK 41.6
MBS ASK 51.6
MBS ASK 61.6
MBS WSK 31.5
MBS WSK 70.6
MBS ASR 201.3
MBS ASR 22.3
MBS ASK 21.3
MBS ASK 31.3
MBS ASK 31.4
MBS ASK 31.5
MBS ASK 41.4
MBS ASK 541.4
MBS ASK 51.4
MBS ASK 61.4
MBS ASK 81.4
MBS ASK 105.6
MBS ASK 105.10
MBS ASK 123.3
MBS ASK 130.3
MBS ASK 130.5
MBS SWMU41.51
MBS SWMU41.52
MBS SWMU42.51
MBS SWMU42.52
MBS ASR 14.3 50/1A 1.5VA Cl.3
MBS ASR 14.3 50/1A 1VA cl.1
MBS ASR 14.3 50/1A 1.5VA Cl.1
MBS ASR 14.3 60/1A 1.5VA Cl.1
MBS ASR 14.3 75/1A 1.5VA Cl.1
MBS ASR 14.3 30/1A 1VA Cl.3
MBS ASR 14.3 50/5A 1VA Cl.1
MBS ASR 14.3 50/5A 1.5VA Cl.1
MBS ASR 14.3 60/5A 1.5VA Cl.1
MBS ASR 14.3 75/5A 1.5VA Cl.1
MBS ASR 14.3 30/5A 1VA Cl.3
MBS ASR 14.3 40/5A 1VA Cl.3
MBS CTM 7 35/1A 0,2VA Kl.1
MBS CTM 7 40/1A 0,3VA Kl.1
MBS CTM 7 50/1A 0,4VA Kl.1
MBS CTM 7 60/1A 0,4VA Kl.1
MBS CTM 7 64/1A 0,5VA Kl.1
MBS ASR 14.3
MBS ASR 20.3
MBS ASR 201.3
MBS ASR 21.3
MBS ASR 21.5
MBS ASR 22.3
MBS ASR 42.45
MBS ASR 22.3 2U
MBS ASG 210.3
MBS ASG 106
MBS ASG 123
MBS AS 176.3
MBS ASK 176.3
MBS ASK 205.3
MBS ASK 21.3
MBS ASK 231.5
MBS ASK 31.3
MBS ASK 318.3
MBS CTB 31.35
MBS ASK 31.4
MBS ASK 31.5
MBS ASK 31.6
MBS ASK 41.3
MBS ASK 421.4
MBS CTB 41.35
MBS ASK 41.4
MBS ASK 41.5
MBS ASK 412.4
MBS ASK 41.6
MBS ASK 541.4
MBS CTB 51.35
MBS ASK 51.4
MBS ASK 51.6
MBS ASK 561.4
MBS CTB 61.35
MBS ASK 61.4
MBS ASK 61.6
MBS ASK 63.4
MBS ASK 63.6
MBS CTB 81.35
MBS ASK 81.4
MBS ASK 83.4
MBS CTB 101.35
MBS ASK 101.4
MBS ASK 103.3
MBS ASK 103.41
MBS ASK 105.6
MBS ASK 105.6N
MBS ASK 123.3
MBS ASK 127.4
MBS ASK 127.6
MBS ASK 128.4
MBS ASK 129.10
MBS ASK 130.3
MBS ASK 130.5
MBS ASK 165.5
MBS ASK 205.5
MBS ASK 31.3 2U
MBS ASK 31.4 2U
MBS ASK 31.4 3U
MBS ASK 31.5 2U
MBS ASK 41.4 2U
MBS ASK 41.4 3U
MBS ASK 412.4 2U
MBS ASK 412.4 3U
MBS ASK 51.4 2U
MBS ASK 51.4 3U
MBS ASK 61.4 2U
MBS ASK 61.4 3U
MBS ASK 81.4 2U
MBS ASK 81.4 3U
MBS ASK 101.4 2U
MBS ASK 103.41 2U
MBS WSK 30
MBS WSK 40
MBS WSK 40N
MBS WSK 60
MBS WSK 70.6
MBS WSK 70.6 N
MBS WSK 31.5
MBS KBR 18
MBS KBR 32
MBS KBR 44
MBS KBU 23
MBS KBU 58
MBS KBU 812
MBS KSU 2
MBS KSU 3
MBS SUSK 3
MBS SUSK 4
MBS SUSK 5
MBS SUSK 6
MBS SUSK 7
MBS SUSK 8
MBS NH 6.1
MBS NH 6.2
MBS NH 6.3
MBS NH 6.1 2U
MBS NH 6.2 2U
MBS NH 6.3 2U
MBS SASR 22.3
MBS SASK 21.3
MBS SASK 31.5
MBS SASK 31.6
MBS SASK 421.4
MBS SASK 41.4
MBS SASK 41.6
MBS SASK 41.10
MBS SASK 541.4
MBS SASK 51.4
MBS SASK 51.6
MBS SASK 61.4
MBS SASK 61.10
MBS SASK 63.6
MBS SASK 105.6
MBS ASRD 14
MBS ASRD 210.3
MBS ASRD 205.37
MBS ASRD 310.37
MBS ASK(D) 21.3
MBS ASK(D) 31.5
MBS ASKD 31.8 mit Bodenplatte
MBS ASKD 31.8 ohne Bodenplatte und Nullleiter
MBS ASK(D) 31.5 2U
北京漢達森德國本土采購，拼箱發貨報關，德國技術，終身售后服務，貨期保證，價格公道，歡迎垂詢!如需更多信息歡迎垂詢漢達森品牌專員吳亞男。
